PULSAR
Cutting condition
(切削参数)
|
|
|
 |
|
1.Steels
& Alloyed Steels (-HRc 20) 钢及合金钢
2.Steels & Alloyed Steels (HRc 20-30) 钢及合金钢
3.Steels & Alloyed Steels (HRc 30-40) 钢及合金钢
4..Steels & Alloyed Steels (HRc 40) -High Temperature
Alloys 钢及合金钢、高温合金
5.Stainless Steels Titaninum Alloys 不锈钢、钛合金
6.Cast Iron (General & Special) 普通铸铁及特殊铸铁
7.Aluminum Alloys 铝合金
8.Copper, Brass, Non-Ferrous Metals 铜、锡及有色金属 |
| |
|
| |
v=Cutting
speed 切削速度
n=Revolution per min. 每分钟转数
u=Feed 进给
s,=Feed per tooth 每齿进给
d=Cutting Diameter in mm 切削直径
z=Number of flute 刃数
π=3.14 |
| |
|
| |
v=dπn/1000
(m/min.)
n=v1000/dπ (Rev./min.)
u=s,z n (mm/min.)
s,=u/n z (mm/tooth)
|
|
| |
|
MATERIAL
GROUP
材质
|
1
|
2
|
3
|
4
|
|
CUTTING
SPEED
切削速度
|
v=35m/min.
|
v=30m/min.
|
v=25m/min.
|
v=20m/min.
|
|
d
|
z
|
n
|
s,
|
u
|
n
|
s,
|
u
|
n
|
s,
|
u
|
n
|
s,
|
u
|
|
2
|
4
|
5500
|
0.011
|
240
|
4800
|
0.011
|
210
|
4000
|
0.01
|
160
|
3200
|
0.005
|
75
|
|
3
|
4
|
3700
|
0.018
|
270
|
3200
|
0.018
|
240
|
2600
|
0.017
|
180
|
2100
|
0.009
|
75
|
|
4
|
4
|
2800
|
0.024
|
270
|
2400
|
0.025
|
240
|
2000
|
0.022
|
180
|
1600
|
0.011
|
75
|
|
5
|
4
|
2200
|
0.03
|
270
|
1900
|
0.031
|
240
|
1600
|
0.028
|
180
|
1300
|
0.014
|
75
|
|
6
|
4
|
1800
|
0.037
|
270
|
1600
|
0.037
|
240
|
1300
|
0.034
|
180
|
1000
|
0.018
|
75
|
|
8
|
4
|
1400
|
0.048
|
270
|
1200
|
0.05
|
240
|
1000
|
0.045
|
180
|
800
|
0.023
|
75
|
|
10
|
4
|
1100
|
0.061
|
270
|
950
|
0.063
|
240
|
800
|
0.056
|
180
|
640
|
0.029
|
75
|
|
12
|
4
|
900
|
0.075
|
270
|
800
|
0.075
|
240
|
660
|
0.068
|
180
|
530
|
0.035
|
75
|
|
14
|
4
|
800
|
0.084
|
270
|
700
|
0.085
|
240
|
570
|
0.079
|
180
|
450
|
0.041
|
75
|
|
16
|
4
|
700
|
0.107
|
300
|
600
|
0.108
|
260
|
500
|
0.11
|
220
|
400
|
0.056
|
90
|
|
20
|
4
|
550
|
0.136
|
300
|
480
|
0.136
|
260
|
400
|
0.137
|
220
|
320
|
0.086
|
100
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MATERIAL
GROUP
材质
|
5
|
6
|
7
|
8
|
|
CUTTING
SPEED
切削速度
|
v=50m/min.
|
v=40m/min.
|
v=100m/min.
|
v=75m/min.
|
|
d
|
z
|
n
|
s,
|
u
|
n
|
s,
|
u
|
n
|
s,
|
u
|
n
|
s,
|
u
|
|
2
|
4
|
8000
|
0.006
|
200
|
6500
|
0.017
|
450
|
16000
|
0.015
|
960
|
12000
|
0.015
|
720
|
|
3
|
4
|
5300
|
0.009
|
200
|
4200
|
0.026
|
450
|
11000
|
0.021
|
960
|
8000
|
0.022
|
720
|
|
4
|
4
|
4000
|
0.012
|
200
|
3200
|
0.035
|
450
|
8000
|
0.03
|
960
|
6000
|
0.03
|
720
|
|
5
|
4
|
3200
|
0.015
|
200
|
2500
|
0.045
|
450
|
6400
|
0.037
|
960
|
4800
|
0.037
|
720
|
|
6
|
4
|
2600
|
0.019
|
200
|
2100
|
0.064
|
540
|
5300
|
0.048
|
1020
|
4000
|
0.048
|
780
|
|
8
|
4
|
2000
|
0.025
|
200
|
1600
|
0.089
|
570
|
4000
|
0.063
|
1020
|
3000
|
0.065
|
780
|
|
10
|
4
|
1600
|
0.031
|
200
|
1300
|
0.115
|
600
|
3200
|
0.079
|
1020
|
2400
|
0.081
|
780
|
|
12
|
4
|
1300
|
0.038
|
200
|
1000
|
0.157
|
630
|
2600
|
0.098
|
1020
|
2000
|
0.097
|
780
|
|
14
|
4
|
1100
|
0.045
|
200
|
900
|
0.183
|
660
|
2300
|
0.11
|
1020
|
1700
|
0.114
|
780
|
|
16
|
4
|
1000
|
0.056
|
225
|
800
|
0.212
|
680
|
2000
|
0.127
|
1020
|
1500
|
0.13
|
780
|
|
20
|
4
|
800
|
0.075
|
240
|
640
|
0.281
|
720
|
1600
|
0.159
|
1020
|
1200
|
0.162
|
780
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
