| PAPS黄铜线(CuZn35) |
|
| |
PAPS公司是韩国最大的慢走丝线切割电极线生产商，该公司出品的镀锌线、黄铜线广泛应用于欧洲、日本产的慢走丝线切割机，切割效率高，加工精度高，易穿丝，是广大慢走丝用户得首选产品。我公司直接从韩国进口，根据不同客户要求提供各种规格、类型的电极线，最大限度的满足客户需求。 |
| |
This wire has a 65:35 Chemical
composition and 980-1,030N/П. This wire made
CiZn alloyed single-structure allows for excellent
cost-performance as standard EDM brass wire.
This wire made by normal Brass allow to be used
normal machine condition at WEDM. The auto Threading
rate can be raised whether the threading mechanism
is pipe type, water jet type, or anneal cutting
type because this wire is very straight. Also,
the surface od PAPS CUT-S wire is treated to
prevent brass powdering. |
|
| |
|
|
| |
 |
 High Quality Raw Material
High Tolerant Wire Diameter
Constant Tensile
Cleaned Wire Surface
Non-Paraffin |
| |
|
|
| |
 |
  Suitable
Mostable |
| Standard
Economic Cutting |
|
| Thick
material Cutting |
|
| High
Accuracy Cutting |
|
| High
Speed Cutting |
|
| Brass
Powderless Cutting |
|
|
| |
|
|
|
|
| |
|
| SPECIFICATION |
|
|
WIRE
GRADE
|
MODEL
NO.
|
DIAMETER
|
DIAMETER
TOLERANCE
|
BREAKING
LOAD(KG)
|
TENSILE
STRENGTH
|
|
|
|
|
|
|
|
HARD
|
PAPS
H-33hw
|
0.013
|
0.33
|
【0.001mm
|
8.38-8.90
|
100-115
|
960-1,020
|
142,000
-
149,000
|
|
PAPS
H-30hw
|
0.012
|
0.30
|
6.92-7.36
|
|
PAPS
H-25hw
|
0.010
|
0.25
|
4.81-5.11
|
|
PAPS
H-20hw
|
0.008
|
0.20
|
3.08-3.27
|
|
PAPS
H-15hw
|
0.006
|
0.15
|
1.731-1.839
|
|
PAPS
H-10hw
|
0.004
|
0.10
|
0.769-0.817
|
|
SOFT
|
PAPS
H-30sw
|
0.013
|
0.33
|
【0.001mm
|
4.28-4.80
|
50-58
|
490-550
|
72,000
-
82,000
|
|
PAPS
H-30sw
|
0.012
|
0.30
|
3.53-3.97
|
|
PAPS
H-25sw
|
0.010
|
0.25
|
2.45-2.75
|
|
PAPS
H-20sw
|
0.008
|
0.20
|
1.57-1.76
|
|
PAPS
H-15sw
|
0.006
|
0.15
|
0.884-0.992
|
|
PAPS
H-10sw
|
0.004
|
0.10
|
0.393-0.441
|
|
|
| |
|
| PRODUCT
LINEUP |
|
|
Products
|
Material
|
Tolerance
of
Diameter/mm
|
Tensile
Strength
|
Recommended
Application
|
|
PAPS-S
|
HW
SW
|
Standard
Brass
|
【0.001mm
【0.001mm
|
960-1,020N/П
490-550N/П
|
Standard
cutting
|
|
PAPS-H
|
HW
SW
|
Special
brass
(More ZN)
|
【0.001mm
【0.001mm
|
1,050-1,110N/П
490-550N/П
|
High
speed & precision
cutting
|
|
PAPS-Hiten
|
HW
|
Special
Alloyed
Brass
|
【0.001mm
|
1,050-1,200N/П
|
High
speed & precision
cutting
|
|
PAPS-EPG
|
HW
SW
|
Standard
ZN coated
|
【0.001mm
【0.001mm
|
910-970N/П
470-530N/П
|
Urtra
high speed &
Better precision cutting
|
|
|
| |
|
| SPOOL DIMENSIONS |
|
|
Spool
Type
|
D
(mm)
|
d
(mm)
|
L
(mm)
|
W
(mm)
|
a
(mm)
|
h
(mm)
|
(kg.)
|
No.
of Spools
Per Carton
(pcs)
|
Spool
Shape
|
|
P-3
|
130
|
80
|
110
|
90
|
10
|
20
|
3
|
6
|
|
|
P-5
|
160
|
90
|
114
|
90
|
12
|
20
|
5-6
|
2/4
|
|
P-10
|
200
|
90
|
134
|
110
|
12
|
25
|
10
|
1
|
|
P-15
|
250
|
110
|
140
|
110
|
15
|
34
|
20
|
1
|
|
P-125
|
125
|
80
|
125
|
100
|
12.5
|
16
|
3.5
|
6
|
|
P-160
|
160
|
100
|
160
|
128
|
16
|
22
|
6-8
|
2
|
|
P-200
|
200
|
125
|
200
|
160
|
20
|
22
|
16
|
1
|
|
P-355
|
355
|
224
|
200
|
160
|
20
|
36
|
45
|
1
|
|
|
| |
|
| |
|
| |
|
|
|
|
| |
|
